- Dimensions
- How to order
- Specification
- Features
Dimensions
| Part No. | End Connections | Dimensions(mm) | |||
| Inlet | Outlet | L ± 1 | |||
| REW02 | F-16R | 1” Female PT | 86.2 | ||
| U-16T | 1” UNILOK Tube Fitting | 162.8 | |||
How to order
| REW02 | U | - | 16T | - | 1 | 1 | 3 | - | 6 |
| Regulator Type |
Connection Type |
Connection Size |
Inlet Pressure |
Outlet Pressure |
Outlet Gauge |
Body Material |
| Regulator Type | Maximum Inlet Pressure | Outlet Gauge | ||||||||||
| REW02 | Regulator | 1 | 16kgf/ cm² | 0 | None | |||||||
| 1 | 0 ~ 10kgf/ cm² | |||||||||||
| Connection Type | Outlet Pressure Range | 2 | 0 ~ 15kgf/ cm² | |||||||||
| F-*R | Female PT | 1 | 1.5 ~ 6.0kgf/ cm² | 3 | 0 ~ 20kgf/ cm² | |||||||
| U-*T | UNILOK Tube Fitting | |||||||||||
| Gauge Port Option | Body Material | |||||||||||
| Connection Size | 0 | 1/4” PF | 6 | 304 Stainless Steel | ||||||||
| 16 | 1 inch | |||||||||||
Specification
| Pressure Ratings | Operating Temperature | Media Contact Materials | |||||
| Max. Inlet Pressure | 16kgf/ cm² | FKM Seat | 0 ~ 80°C (32°F ~ 176°F) | Body | 304 Stainless Steel | ||
| Outlet Pressure Range | 1.5~6.0kgf/ cm² | Piston | 304 Stainless Steel | ||||
| Design Proof Pressure | 150% of maximum rated | Seat | FKM | ||||
Features
- The REW02 series provides excellent stability of set pressure
- For liquid media
- Life cycle superior
- Constantly below maximum permitted pressure to prevent damage
